Lub BAA series agri hub yog ib lub hub bearing system uas muaj tag nrho cov integrated, greased thiab kaw kom ruaj khov rau lub neej ntawm lub unit. Cov hub units no muaj ib lub flanged outer ring uas tau pre-drilled thiab tapped kom haum rau ib lub disc. Lub stationary inner ring muaj ib lub threaded stub shaft kom yooj yim mounting rau ntawm txhua lub caj npab.
| Cov chaw ua liaj ua teb | | | | | | | | |
| Khoom | Qhov Loj | Kev ntsuas qhov hnyav yooj yim |
| D | d | D1 | H | E | S | M | h | dy namic C | C0 zoo li qub |
| mm | mm | mm | mm | mm | mm | mm | mm | Kn | Kn |
| BAA-0003 | 117 | 30 | 98 | 60 | 81 | 4M12X1.25 | | 60 | 44.9 | 34 |
| BAA-0004 | 117 | 30 | 98 | 102 | 81 | 4M12X1.25 | M22X1.5 | 60 | 44.9 | 34 |
| BAA-0006 | 117 | 28 | 98 | 102 | 81 | 6M12X1.25 | M22X1.5 | 60 | 44.9 | 34 |
| BAA-0012 | 117 | 28 | 98 | 102 | 81 | 5M12X1.25 | M22X1.5 | 60 | 44.9 | 34 |
| BAA-0013 | 117 | 28 | 98 | 106 | 81 | 6M12X1.25 | M24X2 | 60 | 44.9 | 34 |
| BAA-0023 | 117 | 28 | 98 | 102 | 81 | 4M12X1.25 | M22X1.5 | 60 | 44.9 | 34 |
| BAA-0005 | 117 | 30 | 98 | 102 | 81 | 4M12X1.25 | M24X2 | 60 | 44.9 | 34 |
